Оправки
Оправки c конусом 7/24 для станков с ЧПУ (DIN69871 A)
h
TH-NC40...G...H
Обозначение
TH-NC40G08H045
TH-NC40G08H070
TH-NC40G08H095
TH-NC40G08H120
TH-NC40G10H050
TH-NC40G10H075
TH-NC40G10H100
TH-NC40G10H125
TH-NC40G10H150
TH-NC40G12H060
TH-NC40G12H085
TH-NC40G12H110
TH-NC40G12H135
TH-NC40G12H160
TH-NC40G16H040
TH-NC40G16H065
TH-NC40G16H090
TH-NC40G16H115
TH-NC40G16H140
TH-NC40G16H165
TH-NC50...G...H
TH-NC50G12H050
TH-NC50G12H100
TH-NC50G12H150
TH-NC50G12H200
TH-NC50G16H050
TH-NC50G16H100
TH-NC50G16H150
TH-NC50G16H200
TH-NC50G16H250
TH-NC50G20H075
TH-NC50G20H100
TH-NC50G20H150
TH-NC50G20H200
TH-NC50G24H095ADB
TH-NC50G24H228ADB
90° 87°
h1
H
Размеры, мм
NC d1
D
h
H h1
40 M08 14,5 10 45 17
40 M08 14,5 10 70 45
40 M08 14,5 10 95 67
40
M08 14,5
10
120
95
40 M10 18,5 10 50 22
40 M10 18,5 10 75 50
40
M10 18,5
10
100
72
40 M10 18,5 10 125 100
40 M10 18,5 10 150 125
40 M12 22 10 60 32
40 M12 22 10 85 60
40 M12 22
10 110 82
40 M12 22
10 135 110
40 M12 22
10 160 135
40 M16 28 10 40 17
40 M16 28 10 65 37
40 M16 28 10 90 65
40 M16 28
10 115 90
40 M16 28
10 140 115
40 M16 28
10 165 140
50 M12 22 10 50 25
50 M12 22
10 100 75
50 M12 22
10 150 128
50 M12 22
10 200 175
50 M16 28 10 50 25
50 M16 28
10 100 75
50 M16 28
10 150 125
50 M16 28
10 200 175
50 M16 28
10 250 228
50 M20 36,2 10 75 50
50
M20 36,2
10
100
75
50 M20 36,2 10 150 125
50 M20 36,2 10 200 175
50 M24 45 20 95 72
50 M24 45
54 228,75 193,7
I4
