Оправки c конусом HSK DIN 69893 Form A
Оправки
h
TH-HA063...G...H
Обозначение
TH-HA063G08H045
TH-HA063G08H070
TH-HA063G08H095
TH-HA063G08H120
TH-HA063G10H050
TH-HA063G10H075
TH-HA063G10H100
TH-HA063G10H125
TH-HA063G10H150
TH-HA063G12H060
TH-HA063G12H085
TH-HA063G12H110
TH-HA063G12H135
TH-HA063G12H160
TH-HA063G16H065
TH-HA063G16H090
TH-HA063G16H115
TH-HA063G16H140
TH-HA063G16H165
TH-HA100...G...H
TH-HA100G12H055
TH-HA100G12H100
TH-HA100G12H150
TH-HA100G12H200
TH-HA100G16H060
TH-HA100G16H100
TH-HA100G16H150
TH-HA100G16H200
TH-HA100G16H250
HSK
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
100
100
100
100
100
100
100
100
100
d1
M8
M8
M8
M8
M 10
M 10
M 10
M 10
M 10
M 12
M 12
M 12
M 12
M 12
M 16
M 16
M 16
M 16
M 16
M 12
M 12
M 12
M 12
M 16
M 16
M 16
M 16
M 16
87°
h1
H
Размеры, мм
d2 D
h
15,5 14,5
10
15,5 14,5
10
15,5 14,5
10
15,5 14,5
10
19,5 18,5
10
19,5 18,5
10
19,5 18,5
10
19,5 18,5
10
19,5 18,5
10
23 22 10
23 22 10
23 22 10
23 22 10
23 22 10
30 28 19
30 28 19
30 28 19
30 28 19
30 28 19
23 22 10
23 22 10
23 22 10
23 22 10
30 28 19
30 28 19
30 28 19
30 28 19
30 28 19
nmax=8 000 об/мин
H h1
45 14
70 39
95 64
120 85
50 16
75 41
100 66
125 91
150 116
60 26
85 51
110 76
135 101
160 126
65 31
90 59
115 81
140 109
165 134
nmax=8 000 об/мин
55 21
100 60
150 110
200 156
60 21
100 60
150 110
200 156
250 206
