СКИФ-М Каталог инструмента 2015
для размещения заказа - info@skif-m-tools.ru
Патроны резьбонарезные 7/24 MAS BT 403
Оправки
H
TH-BT40...M-M
Обозначение
TH-BT40M3-M12
TH-BT40M8-M20
TH-BT40M14-M32
TH-BT50...M-M
TH-BT50M3-M12
TH-BT50M8-M20
TH-BT50M14-M32
BT
40
40
40
50
50
50
Термопатроны 7/24 MAS BT 403
Размеры, мм
dD
19 38
31 53
48 78
19 38
31 53
48 78
H
66,5
93,5
162,5
Размер Резьба
1 M3-M12
2 M8-M20
3 M14-M32
101,5
141,0
164,5
1 M3-M12
Вставки
2 M8-M20 резьбонарезные
3 M14-M32
стр. I42
L
TH-BT40...T...H
Обозначение
TH-BT40T06H090
TH-BT40T08H090
TH-BT40T10H090
TH-BT40T12H090
TH-BT40T14H090
TH-BT40T16H090
TH-BT40T18H090
TH-BT40T20H090
TH-BT40T25H100
TH-BT40T32H100
TH-BT40...T...H
TH-BT40T06H160
TH-BT40T08H160
TH-BT40T10H160
TH-BT40T12H160
TH-BT40T14H160
TH-BT40T16H160
TH-BT40T18H160
TH-BT40T20H160
TH-BT40T25H160
I30
H
нормальное исполнение
Размеры, мм
BT d D L H
40 6 20 36 90
40 8 20 36 90
40 10 24 42 90
40 12 24 47 90
40 14 27 47 90
40 16 27 50 90
40 18 33 50 90
40 20 33 52 90
40 25 44 58 100
40 32 44 58 100
длинное исполнение
40 6 20 36 160
40 8 20 36 160
40 10 24 42 160
40 12 24 47 160
40 14 27 47 160
40 16 27 50 160
40 18 33 50 160
40 20 33 52 160
40 25 44 58 160
TH-BT50...T...H
Обозначение
TH-BT50T06H100
TH-BT50T08H100
TH-BT50T10H100
TH-BT50T12H100
TH-BT50T14H100
TH-BT50T16H100
TH-BT50T18H100
TH-BT50T20H100
TH-BT50T25H110
TH-BT50T32H110
TH-BT50...T...H
TH-BT50T06H160
TH-BT50T08H160
TH-BT50T10H160
TH-BT50T12H160
TH-BT50T14H160
TH-BT50T16H160
TH-BT50T18H160
TH-BT50T20H160
TH-BT50T25H160
TH-BT50T32H160
info@skif-m-tools.ru
www.skif-m-tools.ru
нормальное исполнение
Размеры, мм
BT d D L H
50 6 20 36 100
50 8 20 36 100
50 10 24 42 100
50 12 24 47 100
50 14 27 47 100
50 16 27 50 100
50 18 33 50 100
50 20 33 52 100
50 25 44 58 110
50 32 44 58 110
длинное исполнение
50 6 20 36 160
50 8 20 36 160
50 10 24 42 160
50 12 24 47 160
50 14 27 47 160
50 16 27 50 160
50 18 33 50 160
50 20 33 52 160
50 25 44 58 160
50 32 44 58 160
